The Dong Cheng DMB82 Electric Planer is a reliable, high-speed woodworking tool designed for surface smoothing, edge chamfering, and thickness sizing in timber framing, door fitting, and cabinetry. Powered by a 500W motor producing a rapid 16,000 RPM cutter head speed, it features a dual-blade rotary system that delivers ultra-smooth, uniform stock removal up to 82 mm wide. Outfitted with an easy-to-replace belt-drive transmission and an auxiliary guide plate for straight passes, it ensures consistent precision and durability across carpentry tasks.
Key Features
-
High-Speed 500W Motor: Delivers an impressive 16,000 RPM cutter rotation for rapid, splinter-free planing across softwoods and hardwoods.
-
Double Rolling Blades: Twin-blade cutter block provides clean, balanced cutting action and effortless wood surfacing.
-
Precise 0–1 mm Depth Adjustment: Calibrated depth control knob allows fine micro-adjustments for controlled stock removal.
-
Durable Belt Drive Transmission: High-toughness, wear-resistant drive belt ensures smooth power transfer, protects the motor against jams, and is simple to service.
-
Auxiliary Guide Assembly: Parallel fence guide ensures dead-straight passes along board edges and consistent rebate widths.
Technical Specifications
| Specification |
Details |
| Model |
DMB82 |
| Rated Power Input |
500 W |
| No-load Speed |
16,000 RPM |
| Max. Planing Width |
82 mm (3-1/4″) |
| Max. Planing Depth |
1 mm |
| Drive Type |
Belt Drive |
| Net Weight |
2.9 kg |
Package Includes
-
1 × Dong Cheng Electric Planer (DMB82)
-
1 × Parallel Guide Plate Assembly
-
1 × Blade Sharpening Holder Assembly
-
1 × Blade Setting Gauge
-
1 × Socket Wrench
-
1 × Set of Carbon Brushes
-
1 × User Manual & Color Box Packaging
